FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
" on this table cannot be su
pp
lied.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
E3 : U.S.A. & Canada model E2 : Europe model E1C : China model E1 : Asia model K : Japan model
BK : Black model SP : Premium Silver model
REF No. Part No. Part Name Remarks Q't
y
New
V
er
SEMICONDUCTORS GROUP
D6001,6002 00D9630328409 DIODE , RECTIFIER, AXIAL CVD1N4007ST 2
D6003 00D9430087209 DIODE , ZENER ,1/2W, 24V ZJ24B/HOMI(H.K) COMPANY LTD CVDZJ24BT 1
D6004 90M-HD302450R DIODE , ZENER ,1/2W, 13V ZJ13B/HOMI(H.K) COMPANY LTD CVDZJ13BT 1
D6006 90M-HD302360R DIODE , ZENER ,1/2W, 6.8V ZJ6.8B/HOMI(H.K) COMPANY LTD CVDZJ6.8BT 1
D6301-6303 943202500730S DIODE , ZENER(5.1V/0.5W, SOD-123) CVDMM1Z5V1H 3
D6403 943176010090S L.E.D,(GREEN/RED 5PI) BL-BJEGJ204-L/BRIGHT CVDBLBJEGJ204L 1
D6803 963209003510S DIODE , RELIABLE ESD PROTECTION CDS3C05HDMI1 CVDCDS3C05HDMI1 1
D6835,6836 963209003510S DIODE , RELIABLE ESD PROTECTION CDS3C05HDMI1 CVDCDS3C05HDMI1 2
IC631 943232100380S I.C , DUAL OPAMP(SOP-8P) NJM8080G CVINJM8080G 1
LD621 963262010460S L.E.D (Infrared light emitting diode) SIR-341ST3F / ROHM ROHM CVDSIR341ST3FT0 1
Q6001 943219006820S T.R CVTKTC1027YT 1
Q6002 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q6003,6004 943214500020S T.R,2SC3052 2SC3052(NPN,SC-59,GEISAHAYA CVT2SC3052 2
Q6201 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 1
Q6302 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q6401 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
Q6402,6403 943215500020S T.R,RT1P141C(10K-10K) RT1P141C(PNP,SC-59,SISAHAYA CVTRT1P141C 2
Q6404 943216500020S T.R,RT1N141C(10K-10K) RT1N141C(NPN,SC-59,SISAHAYA CVTRT1N141C 1
RC621 943262100140S SENSOR, REMOTE(37.9KHz) HM238R T-12 GOOD TAKE CRVHM238RT12 1
RESISTOR GROUP
L6501 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R6003 nsp RES, M-OXIDE FILM(1W/4.7ohm) CRG1SANJ4R7RT 1
R6004 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6006,6007 nsp RES, CARBON(1/5W,10ohm,J) CRD20TJ100T 2
R6008 nsp RES, CARBON(1/5W,2.2ohm,J) CRD20TJ2R2T 1 *
R6011 nsp RES, CARBON(1/5W,2.2ohm,J) CRD20TJ2R2T 1 *
R6012-6015 nsp RES, CHIP(1608/5%/220ohm) CRJ10DJ221T 4
R6016 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R6017 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 1
R6018-6021 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 4
R6022 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R6023 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6024 nsp RES, CHIP(1608/5%/39Kohm) CRJ10DJ393T 1
R6025 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 1
R6026,6027 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 2
R6101,6102 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R6103,6104 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R6201,6202 nsp RES, CHIP(1608/5%/390ohm) CRJ10DJ391T 2
R6203 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6206 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6207 nsp RES, CHIP(1608/5%/10ohm) CRJ10DJ100T 1
R6208 nsp RES, CHIP(1608/5%/47Kohm) CRJ10DJ473T 1
R6301 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6302 nsp RES, CHIP(1608/5%/18Kohm) CRJ10DJ183T 1
R6303 nsp RES, CHIP(1608/5%/820ohm) CRJ10DJ821T 1
R6304 nsp RES, CHIP(1608/5%/4.7Kohm) CRJ10DJ472T 1
R6305,6306 nsp RES, CHIP(1608/5%/100Kohm) CRJ10DJ104T 2
R6308 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 1
R6309 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6401,6402 nsp RES, CHIP(1608/5%/10Kohm) CRJ10DJ103T 2
R6403,6404 nsp RES, CHIP(1608/5%/1Kohm) CRJ10DJ102T 2
R6405,6406 nsp RES, CHIP(1608/5%/560ohm) CRJ10DJ561T 2
R6407 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6501 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6601 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6602 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6603 nsp RES, CHIP(1608/5%/180ohm) CRJ10DJ181T 1
R6604 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6605 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6606 nsp RES, CHIP(1608/5%/150ohm) CRJ10DJ151T 1
R6607 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6651 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 1
R6718 nsp RES, CHIP(1608/5%/100ohm) CRJ10DJ101T 1
R6803 nsp RES, CHIP(1608/5%/2.2Kohm) CRJ10DJ222T 1
R6837,6838 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
R6841,6842 nsp RES, CHIP(1608/5%/0ohm) . CRJ10DJ0R0T 2
CAPACIITORS GROUP
C6003 nsp CAP , ELECT(63V/220uF) CCEA1JH221E 1
C6004,6005 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 2
C6007 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C6009 nsp CAP, CHIP(2012, 50V/0.1uF) CCUC1H104KC 1
C6010 nsp CAP, ELECT(16V/10uF)-S CCEA1CKS100T 1
C6011 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6013,6014 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 2
C6015 nsp CAP, CHIP(1608, 50V/330pF) CCUS1H331JA 1
C6016 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 1
C6017 nsp CAP,METAL-FILM(100V/0.047uF) CCME2A473JXT 1
C6021 nsp CAP, MYLAR(100V/0.1uF/J) HCQI2A104JZT 1 *
C6022 nsp CAP, ELECT(50V/10uF)-S CCEA1HKS100T 1
C6113,6114 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 2
C6117 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6202 nsp CAP, ELECT(16V/47uF)-S CCEA1CKS470T 1
C6203 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C6302,6303 nsp CAP, ELECT(50V/1uF) CCEA1HH1R0T 2
C6304 nsp CAP, CHIP(1608, 50V/82pF) CCUS1H820JA 1
C6306 13405012940AS CAP, ELECT(16V/100uF) CCEA1CH101T 1
C6307 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
C6308 nsp CAP, CHIP(1608, 50V/100pF) CCUS1H101JA 1
C6310 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6311 nsp CAP, ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C6312 nsp CAP, ELECT(50V/10uF) CCEA1HH100T 1
C6313 nsp CAP, CHIP(1608, 50V/0.047uF) CCUS1H473KC 1
C6314 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6401,6402 nsp CAP, CHIP(1608, 50V/0.01uF) CCUS1H103KC 2
C6406,6407 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C6501,6502 nsp CAP, CHIP(1608, 50V/1000pF) CCUS1H102KC 2
