FRONT
REF No. Part No. Part Name Remarks Q't
y
New
V
er
C6503,6504 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C6506 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6507 nsp CAP, ELECT(50V/1uF)-S CCEA1HKS1R0T 1
C6508,6509 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 2
C6802 nsp CAP, CHIP(1608, 50V/0.1uF) CCUS1H104KC 1
C6803 nsp CAP, ELECT(10V/220uF)-S KC3-10V221MA5(8*5L) CCEA1AKS221T 1
OTHER PARTS GROUP
BK601,602 nsp BRACKET , FIP CMD1A572-V1 2
BK603 nsp BRACKET , PCB CMD1A569-V1 1
BN321 nsp WIRE ASS'Y ,(5P, 500mm, 2mm PITCH, UL2725, #24/28) CWB8A005500LC 1
CN602 nsp WAFER/ANGLE/2.5mm/07P YMAW025-07R/YEONHO CJP07GB03ZY 1
CN69A nsp WAFER, FFC(40P-1mm,ANGLE) FPC 1.0-11S-40PW/ JCS CJP40GB284ZN 1
! F6001 943652000620S FUSE(372 Series/100mA/TR5) 0.1A, 372 SERIES/TR5 CBA2D0100A3EYT 1
FL601 943172100150S V.F.D (FUTABA, 18-BT-02GINK) FUTABA CFL18BT021GINK 1
JK608 943643101590S JACK, USB STRAIGHT(BLACK 1.5A) YS-UA-002-13 YAOSHENG CJJ9X010Z 1
JK631 943643102440D JACK, MIC(3.5mm, MONO, STRAIGHT) PJ-362HA-4 CJJ1D007Z 1 *
JK651 943643102450D JACK, HEADPHONE(6.35mm, SILVER LING, STRAIGHT) PJ-621HA CJJ2E037Z 1 *
JW602 nsp WIRE ASS'Y (1P, 80MM,BLK,#22) CWE5202080A 1
L6801 nsp FERRITE CHIP BEAD(2012/220R) BLM21PG221SN1/MURATA CLZBLM21PG221SN1 1
LUG65 nsp WIRE ASS'Y CWE8202120RV 1
SW641 00D9430004402 SW , TACT SKHV10910G CST1A012ZT 1
SW661-670 00D9430004402 SW , TACT SKHV10910G CST1A012ZT 10
VR611 943671010330S ENCODER(16MM, 24PULSES),W/CLICK EC16B24SAAD4ZZZ CSR2A055Z 1
VR641 943671010330S ENCODER(16MM, 24PULSES),W/CLICK EC16B24SAAD4ZZZ CSR2A055Z 1
