DISASSEMBLY
Remove each part following the ow below.
Reassemble the removed parts in the reverse order.
Read "Precautions During Work" before reassembling the removed parts.
If wire bundles are removed or moved during adjustment or part replacement, reshape the wires after completing
the work. Failure to shape the wires correctly may cause problems such as noise.
FRONT PANEL ASSY
See "DISASSEMBLY"
1. FRONT PANEL ASSY
and "EXPLODED VIEW"
FRONT PCB
Ref. No. of EXPLODED VIEW : C1
HEAD PHONE PCB
Ref. No. of EXPLODED VIEW : C2
FRONT HDMI FFC CABLE PCB
Ref. No. of EXPLODED VIEW : C3
F_HDMI PCB
Ref. No. of EXPLODED VIEW : C5
USB PCB
Ref. No. of EXPLODED VIEW : C7
FRONT CONT FFC PCB
Ref. No. of EXPLODED VIEW : C12
TOP COVER
MAIN TRANS
See "DISASSEMBLY"
8. MAIN TRANS
and "EXPLODED VIEW"
MAIN TRANS
Ref. No. of EXPLODED VIEW : C21
RADIATOR ASSY
See "DISASSEMBLY"
2. RADIATOR ASSY
and "EXPLODED VIEW"
GUIDE L PCB
Ref. No. of EXPLODED VIEW : C9
AMP PCB
Ref. No. of EXPLODED VIEW : C10
HEATSINK
Ref. No. of EXPLODED VIEW : M12
DIGITAL PCB ASSY
See "DISASSEMBLY"
3. DIGITAL PCB ASSY
and "EXPLODED VIEW"
DIGITAL PCB
Ref. No. of EXPLODED VIEW : C27
GUIDE
Ref. No. of EXPLODED VIEW : C26
CY920 MODULE ASSY
Ref. No. of EXPLODED VIEW : C28
INPUT PCB ASSY
See "DISASSEMBLY"
5. INPUT PCB ASSY
and "EXPLODED VIEW"
INPUT PCB
Ref. No. of EXPLODED VIEW : C22
VIDEO PCB ASSY
See "DISASSEMBLY"
4. VIDEO PCB ASSY
and "EXPLODED VIEW"
VIDEO PCB
Ref. No. of EXPLODED VIEW : C24
SPK PCB ASSY
See "DISASSEMBLY"
6. SPK PCB ASSY
and "EXPLODED VIEW"
SPK PCB
Ref. No. of EXPLODED VIEW : C35
SPK FW PCB
Ref. No. of EXPLODED VIEW : C25
FUSE PCB
Ref. No. of EXPLODED VIEW : C33
FRT CNT PCB
Ref. No. of EXPLODED VIEW : C32
SIDE CONT PCB
Ref. No. of EXPLODED VIEW : C34
SMPS PCB
See "DISASSEMBLY"
7. SMPS PCB
and "EXPLODED VIEW"
SMPS PCB
Ref. No. of EXPLODED VIEW : C13
12
