Denon AVR-X4200W Service Manual

WIRING DIAGRAM
SMPS PCB
INLET
FRONT VFD PCB
FRONT HDMI PCB
78127907 7807 7905
VIDEO PCB
SIDE CNT.PCB
TUNER PACK
AMP PCB
FRONT WIDE PCB
MAIN TRANS
(S3/S4) (S2)
WIRING DIAGRAM
FUNCTION ENCODER
VOLUME ENCODER
CUP12779Z
WIRE/3P/2.5mm/300mm
(S2)
WIRE/4P/2.5mm/220mm
FUSE PCB
CUP12765Z
CUP12627Z-3
CUP12771Z
CUP12770Z
USB JACK PCB
CUP12627Z-1
FL601
CUP12622Z-1
AUX
CUP12627Z-2
CWB8A005450HC
UL2725#24/#28,1P+2C USB
MIC
HEADPHONE PCB
CUP12622Z-2
WAFER/9P/2mm
7805
CJP40GB284ZN
FFC WAFER/23P/1mm
CJP23GA193ZY
CUP12771Z-2
CUP12622Z-3
CUP12639Z
(AVRX4200W)
CN782
WAFER/5P/2.5mm
BN701
BN702
CN706 BN461
Bridge Diode
WiFi AntennaWiFi Antenna
CJP40GA193ZY
CN69B
FFC WAFER/40P/1mm
CN321
WAFER/5P/2mm
CJP05GI288ZY
BN782
CWB1E0051003D
WIRE/5P/2.5mm/100mm
CN932
CJP09GI288ZY
CJP05GI289ZY WAFER/5P/2.5mm
CN940 CN941
WAFER/3P/2.5mm CJP03GI289ZY
FRONT CNT. PCB
CUP12767Z
DIGITAL PCB
CUP12775Z
WAFER/7P/3.96mm
CN971
CJP07GA90ZY
INPUT PCB
CUP12524Y
SPK, REG. PCB
CN704
WAFER/6P/2.5mm
CJP06GI289ZY
CN702
WAFER/5P/2.5mm
CJP05GI289ZY
CN703
WAFER/7P/2.5mm
CJP07GI289ZY
CJP13GI288ZY
CN461
WAFER/13P/2mm
CN701
WAFER/4P/2.5mm
CJP04GI289ZY
WI
RE/7P/2mm/180mm
UL1007#26
BN710
CN69A
FFC WAFER/40P/1mm
CJP07GB03ZY
WAFER/7P/2.5mm
CN602
CN541
WIRE/5P/2mm/450mm
BN321
WIRE/5P/3.96mm/220mm
(AMP PWR)
(S1)
(S3/S4)
(S5/S6)
WIRE/4P/2.5mm/270mm
(FL PWR)
WIRE/2P/3.96mm/130mm
(PRI.)
7805
WAFER/2P/7.92mm
CN902
CJP02GA89ZY
WAFER/2P/3.96mm
CN901
CJP02KA060ZY
CJP05GI289ZY
CWB1B007180LC
CN431
CJP23GA193ZY
(FRONT HDMI)
FFC WAFER/23P/1mm
WAFER/6P/2.5mm
(DIGITAL POWER)
CJP06GA353ZJ
CN903
CN704
CJP07GA208ZY
(7CH AMP)
WAFER/7P/2mm
CN706
CJP03GI288ZY
WAFER/3P/2mm
BN702
BN701
CWB7E0042203D
WIRE/5P/2.5mm/220mm
UL1569#20,105
UL1569#20,105
WIRE/4P/2.5mm/220mm
CWB7E0052203D
UL1569#20,105
WIRE/6P/2.5mm/400mm
BN704
CWB7E0064003D
BN703
CWB7E0071803D
UL1569#20,105
WIRE/7P/2.5mm/180mm
UL1007#26
WIRE/9P/2mm/220mm
BN932
CWB1B009220HC
Network PCB
WiFi Antenna
WiFi Antenna
CON2
CON1
CWB7D006350AGD
WIRE/6P/2.5mm/350mm
BN901
BN461
WIRE/13P/2mm/180mm
CWB1B013180HC
BN706 UL1569#24,105
WIRE/3P/2mm/100mm CWB7C003100HC
130

Denon AVR-X4200W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Component video (YPbPr/YCbCr) out	1
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	FLAC, WAV
Supported radio bands	AM, FM
Internet radio services supported	Pandora, Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby Surround, Dolby TrueHD, DTS-HD Master Audio
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12600 g
