2. Updating via DPMS
Download the latest rmware from our website and update the rmware.
2.1. Network Connection
(1) System Requirements
• Internet Connection by Broadband Circuit
• Modem
• Router
• Ethernet cable (CAT-5 or greater is recommended)
(2) Setting
2.2. Check and update the rmware
Check if there is a rmware update available. It is also possible to check approximately how long the update will take.
(1) Press the "
SETUP
" button on the remote control to display the GUI menu.
(2) Press the cursor button to select "General" → "Firmware" → "Update" → "Check for Update".
(3) Press the "
ENTER
" button.
• The latest version of the rmware uploaded to the web is displayed.
• If the latest rmware version is on the web, proceed to (4).
• If the latest rmware is already installed, press the "
SETUP
" button to exit the menu.
(4) Select "Start" using the cursor buttons, and then press "
ENTER
".
• The power display lights in red and the GUI screen display disappears during the update.
The remaining time of the update is shown on the display of the unit.
Returns to the normal status after update is completed.
---Cautions on Firmware Update---
• For the update procedure, a proper broadband Internet connection environment and settings are required.
• Do not turn off the power until updating is completed.
• It takes around 1 hour to complete the update.
Once an update is started, normal operations cannot be performed until it is completed.
The GUI menu settings and image adjustment settings of this unit may be initialized.
Note down the settings before updating, and set them again after updating.
Modem
Internet
Computer
ComputerLAN port / Ethernet connector
Ethernet connector of this Unit
Router
To WAN port
To LAN port
To LAN port
90
To Next Page
