2-1. DIAGNOSTIC MODE (Service Path Check Mode)
2-1.1. Actions
This function is convenient for conrming problem paths in the product and checking the paths after repairing.
The Video and Audio paths can be checked.
The backup data is not rewritten.
2-1.2. Starting up
While holding down buttons "
STATUS
" and "
ZONE3 SOURCE
" simultaneously, press the power button to turn on the power.
Select "
1.SERVICE CHECK
", then press the "
ENTER
" button to activate the diagnostic mode.
The "
TUNED
", "
STEREO
" and "
RDS
" segments are lit in this mode.
2-1.3. Canceling diagnostic mode
Press the power button to turn off the power.
2-1.4. Selecting items to check
Press the
q
button to switch between video items and audio items.
Press the
w
or
e
button to select the previous or next item.
The unit Remote control unit
Actions
q w e q w e
Audio ⇔ Video PREVIOUS NEXT Audio ⇔ Video PREVIOUS NEXT
Button DIMMER CURSOR
0
CURSOR
1
SLEEP CURSOR
0
CURSOR
1
2-1.5. Audio system conrmation items
See the block diagram g.XXth.
Paths to be conrmed Display Settings What to conrm
1
Analog
(MAIN ZONE)
A 0 1 : A N A L O G P A S S
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : DIRECT
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R)
・Analog input ⇒ Preout output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
2
Digital
(MAIN)
A 0 2 : D I G I T A L
Input Source : CBL/SAT
Input Mode : DIGITAL (xed)
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small / SW = Yes(2ch)
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Digital input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・Digital input ⇒ Pre output (Front L/R, Center, Surround L/R, Surround Back L/R, Subwoofer)
(
b
The input source can be switched to any source except CBL/SAT.)
3
Digital
(ZONE2)
A 0 3 : D I G I T A L - Z 2
Input Source : Online Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 5.1ch + ZONE2
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
・Digital(PCM) input ⇒ Amp Assign Speaker (Surround Back L/R → ZONE2 L/R)
・Digital(PCM) input ⇒ Preout output (ZONE2 L/R)
(
b
The input source can be switched to any source except Online Music.)
4
Digital
(ZONE3)
A 0 4 : D I G I T A L - Z 3
Input Source : Online Music
Input Mode : Auto
Sound mode : STEREO
Amp assign : 5.1ch + ZONE3
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : ON
・Digital(PCM) input ⇒ Amp Assign Speaker output (Surround Back L/R → ZONE3 L/R)
・Digital(PCM) input ⇒ Preout output (ZONE3 L/R)
(
b
The input source can be switched to any source except Online Music.)
g.01
g.02a
g.02b
g.03a
g.03b
g.03c
g.04a
g.04b
25
