Denon AVR-X4200W Service Manual

Paths to be conrmed Display Settings What to conrm
5
HDMI
A 0 5 : H D M I
Input Source : CBL/SAT
Input Mode : HDMI (xed)
Sound mode : STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・HDMI input ⇒ Speaker output (Front L/R)
・HDMI input ⇒ Preout output (Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
6
Analog A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog (xed)
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor
Speaker Cong ALL Speaker = Small/SW = Yes(2ch)
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front L/R, Center, Surround L/R, Surround Back L/R)
・Analog input ⇒ Preout output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
7
Analog Amp Assign
(Amp Assign : ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Amp assign : 5.1ch + ZONE2
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : OFF
・Analog input ⇒ Speaker input (Surround Back L/R → ZONE2 L/R)
・Analog input ⇒ Preout input (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
8
Analog Amp Assign
(Amp Assign : ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z3 Source : Source
Amp assign : 5.1ch + ZONE3
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : ON
・Analog input ⇒ Speaker output (Surround Back L/R → ZONE3 L/R)
・Analog input ⇒ Preout output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
9
Analog Amp Assign
(Amp Assign : ZONE2/ZONE3-MONO)
A 0 9 : A S S I G N - Z 3 / 3 M
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : STEREO
Z2 Source : Source
Z3 Source : Source
Amp assign : 5.1ch + ZONE2/3 MONO
MAIN ZONE : ON
ZONE2 : ON
ZONE3 : ON
・Analog input ⇒ Speaker output (Surround Back L → ZONE2 MONO) (Surround Back R → ZONE3 MONO)
・Analog input ⇒ Preout output (ZONE2 L/R MONO) (ZONE3 L/R MONO)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
10
Amp Assign
(Bi-Amp)
A 1 1 : A S S I G N - B i A M P
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 5.1ch + Bi-Amp
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R → Front L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
11
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Height1 L/R → Front Height)
・Analog input ⇒ Preout output (Height1 L/R → Front Height)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
g.05a
g.05b
g.05c
g.06a
g.06b
g.07
g.08
g.09
g.10a
g.10b
g.11a
g.11b
26

Denon AVR-X4200W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Component video (YPbPr/YCbCr) out	1
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	FLAC, WAV
Supported radio bands	AM, FM
Internet radio services supported	Pandora, Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby Surround, Dolby TrueHD, DTS-HD Master Audio
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12600 g
