Denon AVR-X4200W Service Manual

Paths to be conrmed Display Settings What to conrm
12
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 7.1ch
Floor Layout : 5ch&FW
Height Sp : None
Dolby Sp : None
Speaker Select : Front
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
13
Front Amp>>Front Wide
A 2 1 : F - A M P W I D E
Input Source : CBL/SAT
Input Mode : Auto
SURROUND mode : Multi ch STEREO
Amp assign : 9.1ch
Floor Layout : 5ch&SB&FW
Height Sp : None
Dolby Sp : None
Pre-out Channel : Front
Speaker Select : Floor
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Front Wide L/R)
・Analog input ⇒ Preout output (Front Wide L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
14
Front Amp>>Surround Back
A 2 2 : F - A M P B A C K
Input Source : CBL/SAT
Input Mode : Auto
SURROUND mode : Multi ch STEREO
Amp assign : 9.1ch
Floor layout : 5ch&SB
Height Sp : 2ch
Dolby Sp : None
Height Layout : Front Height
Pre-out Channel : Front
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Speaker output (Surround Back L/R)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
15
Height
A 2 4 : H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : MULTI CH STEREO
Amp assign : 9.1ch
Floor Layout : 5ch
Height Sp : 4ch
Dolby Sp : None
Height Layout : Top Front & Top Rear
Pre-out Channel : Top Rear
Speaker Select : Floor & Height
MAIN ZONE : ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ Preout output (Height1 L/R → Top Front) (Height2 → Top Rear)
(
b
The input source can be switched to any source except CBL/SAT.)
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used)
g.12a
g.12b
g.13a
g.13b
g.14a
g.14b
g.15a
g.15b
27

Denon AVR-X4200W Specifications

General

Receiver type	Surround
Audio output channels	7.2 channels
Power output per channel (1KHz@6 Ohm)	235 W
Power output per channel (20-20KHz@8 Ohm)	125 W
HDMI in	8
Audio (L/R) in	6
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Number of HDMI outputs	3
Component video (YPbPr/YCbCr) out	1
12V trigger	Yes
Speakers connectivity type	-
Audio formats supported	FLAC, WAV
Supported radio bands	AM, FM
Internet radio services supported	Pandora, Spotify, vTuner
Optical drive included	No
Product color	Silver
Audio decoders	Dolby Surround, Dolby TrueHD, DTS-HD Master Audio
Power consumption (standby)	0.1 W
Power consumption (typical)	670 W

Weight and Dimensions

Depth	379 mm
Width	434 mm
Height	167 mm
Weight	12600 g
