TP search
TP identifies programs that carry traffic announcements.
This allows you to easily find out the latest traffic conditions in your area
before leaving home.
Use this function to find RDS stations broadcasting traffic programs (TP
stations).
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui to select “TP Search”, then press ENTER.
3
Press ENTER.
TP search begins automatically.
0
If you use o p within 5 seconds after the broadcast station name is shown on the
display, you can search for a different station.
Radio Text
RT allows RDS stations to send text messages that appear on the display.
“Radio text” appears on the display when radio text data is received.
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui to select “Radio text”, then press ENTER.
3
Use o p to select “On”, then press ENTER.
0
While receiving an RDS broadcast station, the text data
broadcast from the station is displayed.
0
If no text data is being broadcast, “NO TEXT DATA” is displayed.
Contents Connections Playback Settings Tips Appendix
108
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6300H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6300H and is the answer not in the manual?

Denon AVR-X6300H Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 10000 Hz
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)175 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeRCA
Display-
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts platingGold
Apple docking compatibilityNot supported
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Internet radio services supportedNapster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive includedNo
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)750 W
Supported video modes2160p
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height235 mm
Weight14500 g
