Page #284 background imageLoading...
Page #284 background image
o
The Internet radio cannot be played back
Symptom Cause / Solution Page
A list of broadcasting
stations is not displayed.
0
The LAN cable is not properly connected, or the network is disconnected. Check the connection status. 86
0
Perform the network diagnostic mode.
Internet Radio cannot be
played.
0
The selected radio station is broadcasting in a format that is not supported by this unit. Formats that can
be played back in this unit are MP3, WMA and AAC.
299
0
The firewall function is enabled on the router. Check the firewall setting.
0
The IP address is not properly set. 242
0
Check the power of the router is on.
0
To obtain the IP address automatically, enable the DHCP server function on the router. Also, set the
DHCP setting to “On” on this unit.
242
0
To obtain the IP address manually, set the IP address on this unit. 242
0
Some radio stations broadcast silently during some time period. In this case, no audio is output. Wait for a
while and select the same radio station, or select another radio station.
115
0
The selected radio station is not in service. Select a radio station in service.
Cannot connect to favorite
radio stations.
0
Radio station is not currently in service. Register radio stations in service.
Contents Connections Playback Settings Tips Appendix
284
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6300H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6300H and is the answer not in the manual?

Denon AVR-X6300H Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 10000 Hz
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)175 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeRCA
Display-
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts platingGold
Apple docking compatibilityNot supported
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Internet radio services supportedNapster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive includedNo
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)750 W
Supported video modes2160p
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height235 mm
Weight14500 g
