o
Pre-out
When “Assign Mode” is set to “11.1ch”, selects the PRE OUT
connector the external power amplifier used in MAIN ZONE.
The PRE OUT connectors that can be selected differ depending on the
combination of “Floor” - “Layout” and “Height” - “Layout” settings
configured in the menu.
o
View Terminal Config.
This shows how to connect the speaker terminals and PRE OUT
connectors for your “Amp Assign” setting on the menu screen.
Speaker Config.
Select whether or not speakers are present, playback capacity for low
bass frequencies and speaker size.
0
When speakers for which you assigned Height1 in “Amp Assign” are set to “None”,
“None” is automatically set for Height2.
o
Front
Set the front speaker size.
Large
(Default):
Use a large speaker that can adequately
play back very low bass frequencies.
Small:
Use a small speaker that has inadequate
playback capacity for very low bass
frequencies.
0
When “Subwoofer” is set to “No”, “Front” is automatically set to “Large”.
0
When “Front” is set to “Small”, you cannot set speakers other than “Front” to
“Large”.
Contents Connections Playback Settings Tips Appendix
226
Front panel Display Rear panel Remote Index
