Speaker configuration and “Amp Assign” settings
This unit has a built-in 9-channel power amplifier. In addition to the basic 5.1-channel system, a variety of speaker systems can be configured by changing
the “Amp Assign” settings to suit the application, such as 7.1-channel systems, bi-amp connections and 2-channel systems for multi-zone playback.
(v p. 219)
Perform “Amp Assign” settings to suit the number of rooms and speaker configuration to be installed. (v
p. 219)
Playback speaker in each zone
“Amp Assign” settings
Connection
page
MAIN ZONE ZONE2 ZONE3
5.1-channel playback
2-channel (Pre-out) 2-channel (Pre-out)
Can be set in all “Amp
Assign” modes.
46
7.1-channel playback 7.1ch + ZONE2 47
9.1-channel playback 9.1ch (Default) 51
11.1-channel playback 11.1ch 60
7.1-channel playback (bi-amp connection of front
speakers)
7.1ch (Bi-Amp) 66
Second front speakers 7.1ch + Front B 67
7.1-channel playback 2-channel
(Speaker out)
2-channel (Pre-out) 7.1ch + ZONE2 68
7.1-channel playback 2-channel (Pre-out) 2-channel
(Speaker out)
7.1ch + ZONE3 68
5.1-channel playback (bi-amp connection of front
speakers)
2-channel
(Speaker out)
2-channel (Pre-out) 5.1ch (Bi-Amp) + ZONE2 69
5.1-channel playback 2-channel
(Speaker out)
2-channel
(Speaker out)
5.1ch + ZONE2/3 70
7.1-channel playback 1-channel
(Speaker out)
1-channel
(Speaker out)
7.1ch + ZONE2/3-MONO 71
The sound mode that can be selected varies according to the speaker configuration. See “Relationship between sound modes and channel output”
(v p. 300) for the sound modes that are supported.
The following pages provide basic connection examples.
Contents
Connections Playback Settings Tips Appendix
44
Front panel Display Rear panel Remote Index
