Upgrade (Auro-3D)
Refer to the example connection for “Example connection for the Auro-3D
9.1-channel system” (v
p. 57) when playing Auro-3D with a 9.1-
channel system using the basic 5.1-channel system and the front height
and surround height speakers.
Also refer to the connection example for “Example connection for the
Auro-3D 10.1-channel system” (v
p. 63) when playing Auro-3D with a
10.1-channel system by adding the top surround speaker.
0
In addition to the connections described in
p.46 - 71, this unit allows for various
speaker connections with the “Amp Assign” setting.
Also refer to the menu screen in “View Terminal Config.” on the “Amp Assign”
setting screen, which shows how to make connections in your environment.
.
CENTER SURROUND SURROUNDFRONTFRONT CENTER SURROUND SURROUNDFRONTFRONT
SUBWOOFER
12
HEIGHT1 HEIGHT1T.FRONT T.FRONT
T.REAR
SURR.BACK SURR.BACK
Speakers/Amp Assign
Back
PRE OUT
SPEAKERS
Assign Mode 11.1ch
