Skipping preset broadcast stations
(Preset Skip)
Perform auto preset memory to save all the broadcasting stations that can
be received in the memory. Selecting a broadcast station becomes easier
by skipping unnecessary memories.
1
Press OPTION when the input source is “Tuner”.
The option menu screen is displayed.
2
Use ui to select “Preset Skip”, then press ENTER.
The “Preset Skip” screen is displayed.
3
n
To set the stations you want to skip by groups
A
Use o p to select the group of broadcast stations you want to
skip.
B
Press u to select “Set No.zz to Skip”, then press ENTER.
Skip all the broadcast stations that are included in the
selected group “z-z”.
(z is the selected group number.)
n
To set the stations you want to skip by stations
A
Use o p to select the group of broadcast stations you want to
skip.
B
Use ui to select the broadcast station you want to skip.
C
Use o p to select “Skip”.
The station you selected is not displayed.
4
Press OPTION to return to the previous screen.
Contents Connections Playback Settings Tips Appendix
112
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6300H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6300H and is the answer not in the manual?

Denon AVR-X6300H Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 10000 Hz
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)175 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeRCA
Display-
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts platingGold
Apple docking compatibilityNot supported
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Internet radio services supportedNapster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive includedNo
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)750 W
Supported video modes2160p
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height235 mm
Weight14500 g
