Explanation of terms
o
Audyssey
Audyssey Dynamic EQ
®
Dynamic EQ solves the problem of deteriorating sound quality as volume
is decreased by taking into account human perception and room
acoustics.
Audyssey Dynamic EQ
®
works in tandem with Audyssey MultEQ
®
XT32
to provide well-balanced sound for every listener at any volume level.
Audyssey Dynamic Volume
®
Dynamic Volume solves the problem of large variations in volume level
between television programs, commercials, and between the soft and loud
passages of movies. Audyssey Dynamic EQ
®
is integrated into Dynamic
Volume so that as the playback volume is adjusted automatically, the
perceived bass response, tonal balance, surround impression, and dialog
clarity remain the same.
Audyssey LFC™ (Low Frequency Containment)
Audyssey LFC™ solves the problem of low frequency sounds disturbing
people in neighboring rooms or apartments. Audyssey LFC™ dynamically
monitors the audio content and removes the low frequencies that pass
through walls, floors and ceilings. It then applies psychoacoustic
processing to restore the perception of low bass for listeners in the room.
The result is great sound that no longer disturbs the neighbors.
Audyssey MultEQ
®
XT32
Audyssey MultEQ
®
XT32 is a room equalization solution that calibrates
any audio system so that it can achieve optimum performance for every
listener in a large listening area. Based on several room measurements,
MultEQ
®
XT32 calculates an equalization solution that corrects for both
time and frequency response problems in the listening area and also
performs a fully automated surround system setup.
Contents
Connections Playback Settings Tips Appendix
310
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6300H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6300H and is the answer not in the manual?

Denon AVR-X6300H Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 10000 Hz
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)175 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeRCA
Display-
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts platingGold
Apple docking compatibilityNot supported
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Internet radio services supportedNapster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive includedNo
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)750 W
Supported video modes2160p
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height235 mm
Weight14500 g
