Page #137 background imageLoading...
Page #137 background image
Adjusting the tone (Tone)
Adjusts the tonal quality of the sound.
1
Press OPTION.
An option menu screen is displayed.
0
When the input source is “Online Music”, an option menu for
online music is displayed. Select “AVR Options…”, then press
ENTER.
2
Use ui to select “Tone”, then press ENTER.
The “Tone” screen is displayed.
3
Use o p to set the tone control function to on/off.
On: Allow tone adjustment (bass, treble).
Off
(Default):
Playback without tone adjustment.
4
Select “On” in step 4 and press i to select the sound
range to be adjusted.
Bass: Adjust bass.
Treble: Adjust treble.
5
Use o p to adjust the tone, then press ENTER.
-6 dB – +6 dB (Default : 0 dB)
0
“Tone” settings are stored for each input source.
0
This cannot be set when the sound mode is set to “Direct” or “Pure Direct”.
0
This item cannot be set when “Dynamic EQ” is set to “On”. (v
p. 186)
0
You cannot set this when no audio signal is input or in the menu “HDMI Audio Out”
is set to “TV”. (v p. 192)
Contents Connections Playback Settings Tips Appendix
137
Front panel Display Rear panel Remote Index

Table of Contents

Other manuals for Denon AVR-X6300H

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Denon AVR-X6300H and is the answer not in the manual?

Denon AVR-X6300H Specifications

General IconGeneral
Receiver typeSurround
Frequency range10 - 10000 Hz
Input sensitivity200 mV
Pre-out connectivityYes
Audio output channels11.2 channels
Signal-to-Noise Ratio (SNR)100 dB
Power output per channel (1KHz@6 Ohm)175 W
Power output per channel (20-20KHz@8 Ohm)140 W
HDMI in8
Composite video in4
Ethernet LAN (RJ-45) ports1
Component video (YPbPr/YCbCr) in2
Headphone connectivity3.5 mm
Multichannel audio output typeRCA
Display-
Audio decodersDTS-HD Master Audio, Dolby Surround, Dolby TrueHD
Connector contacts platingGold
Apple docking compatibilityNot supported
Connectivity technologyWired & Wireless
Speakers connectivity type3.5mm
Audio formats supportedAAC, ALAC, DSD, FLAC, MP3, WAV, WMA
AM band range520 - 1710 kHz
FM band range87.5 - 107.9 MHz
Supported radio bandsAM, FM
Internet radio services supportedNapster, Pandora, SIRIUS Internet Radio, Spotify, TuneIn
Optical drive includedNo
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.1 W
Power consumption (typical)750 W
Supported video modes2160p
Weight and Dimensions IconWeight and Dimensions
Depth339 mm
Width434 mm
Height235 mm
Weight14500 g
