56
D-A03
JK1 951 0069 600 4P antenna terminal for E3 1
JK301 951 0059 801 Mini jack 1
JK302 951 0059 704 1P pin jack 1
JK303 951 0010 808 Mini jack 1
JP10-14 951 9002 600 Carbon chip 0 ohm 1/16W 5
JP176,177 GP3 8002 006 Diode 1N4148 for E1H 2
JP23-26 951 9002 600 Carbon chip 0 ohm 1/16W 4
JP3 951 9002 600 Carbon chip 0 ohm 1/16W for E3 1
JP33-37 951 9002 600 Carbon chip 0 ohm 1/16W for E1H 5
JP402-404 951 9002 600 Carbon chip 0 ohm 1/16W 3
JP40-45 951 9002 600 Carbon chip 0 ohm 1/16W for E3 6
L103-105 951 0063 402 Inductor 2.2uH 3
L106 951 0063 509 Inductor 1uH 1
L107 951 0063 402 Inductor 2.2uH 1
L109 951 0069 707 Beads inductor 1
L404 951 0063 305 Inductor 100uH 1
L405 951 0069 707 Beads inductor 1
L601,602 951 0063 402 Inductor 2.2uH 2
RF401 951 0046 500 FM tuner module KCF217V 1
S603 951 0062 005 Tact switch 1
S604-607 951 0010 905 Tact switch 4
S609 951 0010 905 Tact switch 1
S611,612 951 0010 905 Tact switch 2
S613 951 0062 005 Tact switch 1
S615 951 0062 005 Tact switch 1
S617 951 0062 005 Tact switch 1
S618 951 0010 905 Tact switch for E1H 1
S619 951 0062 005 Tact switch 1
T401 951 0019 508 AM IF coil 1
T402 951 0069 901 AM antenna coil 1
T403 951 0070 000 AM OSC coil 1
T404 951 0019 207 FM DET IFT coil 1
W1 951 0025 819 3P connector base 1
W104 951 0070 107 4P connector base 1
W2 951 0026 216 3P connector base 1
X101 GP3 8002 050 Crystal 16.9344MHz 1
X601 951 0062 209 Crystal 8.3886MHz 1
XTL401 951 0062 102 Crystal 4.5000MHz 1
951 0023 808 Fuse label 4A/125V for E3 1
951 0070 204 Fuse label T4A/250V for E1H 1
951 0023 824 Fuse label 2.5A/250V for E3 1
951 0070 301 Fuse label T2.5A/250V for E1H 1
951 0038 301 Cover 8
951 0070 408 Rubber for E1H 1
UL PVC tube (1) for E1H 1
UL PVC tube (2) 1
GP3 8003 011 Fuse holder 4
951 9001 070 Screw 3x6 CBTS(S) 4
951 0068 203 11P wire Ass’y L=150 (PH) for E1H 1
Heat sink 1
951 0065 507 Heat sink bracket (L) 1
951 0065 701 Heat sink bracket (R) 1
951 9001 151 Screw 3x8 CBTS(S) 6
GP3 8009 004 Screw 3x10 CBTS(S) 2
951 0034 004 Fuse 4A/250V for E1H 1
951 0034 101 Fuse 2.5A/250V for E1H 1
Lug 1
Wire BK L=100 1
951 0070 505 Rubber foam 1
951 0070 602 Ferrite core for E1H 3
951 0070 602 Ferrite core for E3 2
UL tube (5) 1
951 0064 207 PWB bracket 2
951 9001 070 Screw 3x6 CBTS(S) for E3 2
Lug 1
951 0069 804 10P wire Ass’y L=400 (PH) for E1H 1
951 0025 000 3P wire Ass’y L=350 (EH) for E3 1
Wire BK L=30 1
951 0070 709 Voltage selector for E1H 1
Wire BN L=250 for E1H 2
951 0070 806 AC inlet for E1H 1
Wire BK L=80 for E1H 1
UL PVC tube (1) for E3 1
Wire RD L=180 for E3 1
Wire WH L=40 for E3 2
Ref. No. Part No. Part Name Remarks Q'ty Ref. No. Part No. Part Name Remarks Q'ty
