Ref. No. Part No. Part Name Remarks
DISPLAY P.W.B. UNIT ASSY
SEMICONDUCTORS GROUP
IC501 951 0023 400 IC LC75811W
D501 GP3 8002 006 Diode 1N4148
RESISTORS GROUP
R501 951 0025 204 Metal oxide 2.2 ohm 1W
R502 951 9002 820 Carbon chip 33 kohm 1/16W
R503 951 9002 859 Carbon chip 3.3 kohm 1/16W
R504 951 9002 875 Carbon chip 3.9 kohm 1/16W
R505 951 9002 642 Carbon chip 12 kohm 1/16W
R506 951 9003 476 Carbon chip 8.2 kohm 1/16W
R507 951 9003 845 Carbon film 220 ohm 1/8W
R508 951 9002 684 Carbon chip 1 kohm 1/16W
CAPACITORS GROUP
C501 951 9001 766 Ceramic chip 220pF/50V
C502-505 951 9003 560 Ceramic chip 0.1uF/16V
C506 951 9003 418 Electrolytic 47uF/16V
C508 951 9003 418 Electrolytic 47uF/16V
C509 951 9003 560 Ceramic chip 0.1uF/16V
C510-512 951 9003 751 Ceramic chip 0.0012uF/50V
OTHER PARTS GROUP Q'ty
CY071 951 0025 408 7P wire Ass’y L=250 1
FL501 951 0063 606 LCD TSB0716-UGTDPW 1
951 0061 608 Color filter sheet WH 1
951 0061 909 5V/220mA lamp 4
951 0007 905 Lamp cap BU 4
473 7500 015 Screw 3x8 CBTS(S) 2
PVC washer 2
951 0004 102 LCD reflector 1
951 0025 301 LCD shield plate 1
