13
DN-D4500
100 P54,BSTRE LDEND2 I iPu Loading end (CD2)
101 P55,WR_ O iPu Reserved
102CS3_ CS3_ O----Not used
103A00 A00 O----Ext. memory address 0
104A01 A01 O----Ext. memory address 1
105A02 A02 O----Ext. memory address 2
106A03 A03 O----Ext. memory address 3
107A04 A04 O----Ext. memory address 4
108A05 A05 O----Ext. memory address 5
109A06 A06 O----Ext. memory address 6
110A07 A07 O----Ext. memory address 7
111A08 A08 O----Ext. memory address 8
112 PD6 OPENSW2 I iPu CD2 Tray open SW
113 PD7,TM7IO CLOSESW2 I iPu CD2 Tray close SW
114A09 A09 O----Ext. memory address 9
115A10 A10 O----Ext. memory address 10
116A11 A11 O----Ext. memory address 11
117A12 A12 O----Ext. memory address 12
118A13 A13 O----Ext. memory address 13
119VDD VDD -----Power (+3.3V)
120 PC4 INSW2 I iPu CD2 Inner SW L:ON
121A14 A14 O----Ext. memory address 14
122A15 A15 O----Ext. memory address 15
123A16 A16 O----Ext. memory address 16
124A17 A17 O----Ext. memory address 17
125A18 A18 O----Ext. memory address 18
126 A19 A19 O - Pd - - Ext. memory address 19
127A20 A20 O----Ext. memory address 20
128A21 A21 O----Ext. memory address 21
Pin No. Pin Name Simbol I/O DET Ext Ini Res Function
