21
Q1 Key lock button (KEY LOCK) ····················· (15)
With this ON, the key does not change even if
you adjust the tempo during playback.
Q2 Sample mode switching button (SAMPLE)
•OFF: Switches to the hot cue mode.
HOT CUE 1 – 4 are used to operate the hot
cues.
•ON: Switches to the sample mode.
HOT CUE 1 – 4 are used to operate the sample
player.
Q3 Jog wheel ···················································· (15)
Performs the search operation or bend operation.
Q4 Pitch fader slider
Adjusts the playback pitch.
•Move the knob toward the “–” direction to
slow down the pitch and the “+” direction to
speed up the pitch.
Q5 Beat synchronization button (SYNC)
Performs auto beat matching.
•Hold Q0 SHIFT and press this button to exit the
beat matching.
Q6 Cue button (CUE)
Sets the cue point and stutters the cue point
when pushed repeatedly.
Q7 Play/pause button (1/3)
Plays back when pressed while playback is
stopped. Pauses playback when pressed during
playback.
Q8 Censor ON/OFF switching button (CENSOR)
Q9 Pitch bend adjustment buttons
(PITCH BEND –/+)
Adjust the pitch temporarily.
•Hold down Q0 SHIFT and press this button to
fast forward/rewind.
W0 VINYL mode switching button (VINYL)
ON: Switches to VINYL mode.
•The touch sensor is enabled when in VINYL
mode. At this time, the jog wheel can be used
for scratching.
OFF: Switches to BEND mode.
•The touch sensor is disabled when in BEND
mode.
W1 Panel display button (PANEL) ··················· (16)
W2 View button (VIEW)
W3 X-F Link button (X-F LINK) ·················· (15, 16)
Switches the cross fader mode (AUDIO/VIDEO/
BOTH).
W4 Area button (AREA)
W5 List button (LIST) ········································ (16)
Top panel
