14
RCD-CX1
(3) Remove the screws.（ねじをはずす。）
5. SACD MECHA ASSY
(1) Disconnect the connector wires. ( コネクタワイヤーをはずす。)
Picture D
FRONT ANGLE
TOP PANEL BRACKET
Proceeding (手順) : TOP PANEL → SIDE PANEL
　　→ TOP ANGLE → SW POWER UNIT → SHIELD BRACKET
　　→ FRONT PANEL SUB ASSY → TOP PANEL BRACKET
　　→ FRONT ANGLE → SACD MECHA ASSY
FFC CABLE
Top v iew
CY091
CORD HOLDER : Loose
