Denon RCD-N8

17
2. CD MECHA ASSY
(1) Remove the screws.
(2) Laser short-circuit in Pick-up of CD MECHANISM ASS'Y, then disconnect the connector wires and FFC cable.
Be sure to wear a grounding band.
(3) Remove the connector wire.
Proceeding : SIDE PANEL
TOP COVER
→ →
CD MECHA ASSY
FFC
Shooting direction: A
Soldering place
Shooting direction: C
