3. FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the clamp bands, remove the connector wire and FFC.
Proceeding : SIDE PANEL
TOP COVER
→ →
FRONT PANEL ASSY
View from the bottom
CP301
CON2
CON1
CP104
Cut
CN401
Shooting direction: D
