Denon RCD-N8 Service Manual

47
Check Digital Audio Data input for PWM CONTROLLER.
MAIN B'D
• [IC108] : 26,27,28pin
5508_LRCK,5508_SCLK,5508_SDATA
Check PWM Audio Data from PWM CONTROLLER.
MAIN B'D
• [IC108] : 44,45,46,47pin
Check PWM Audio Data output for PWM CONTROLLER.
MAIN B'D
• [IC118] : 4, 6, 14, 16 pin
Check Audio Data output from AMP to SPEAKER.
MAIN B'D
• [IC118] : 22, 25, 30, 33 pin
• [JACK105]
OK
OK
OK
Check Soldering.
• [IC108] : 26,27,28pin on MAIN B'D
Check Soldering.
• [IC108] on MAIN B'D
Check Soldering.
• [IC118] on MAIN B'D
Check Soldering.
• [IC118] on MAIN B'D
• [JACK105] on MAIN B'D
NG
NG
NG
NG
END

Denon RCD-N8 Specifications

General

Remotely operated	Yes
Security algorithms	WPS
Supported radio bands	FM, VHF
Built-in storage media	No
Audio formats supported	MP3
Internet radio services supported	iDevice, iTunes
Network streaming services supported	-
Product color	White
RMS rated power	130 W
Wi-Fi standards	802.11b, 802.11g
Digital audio optical out	1
Apple docking compatibility	iPhone, iPod
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	50 W

Weight and Dimensions

Depth	299 mm
Width	280 mm
Height	112 mm
Weight	4000 g
