Pin No Pin Name Port Name PD/PU I/O STBY
Network
STBY
Eco
STBY
Note
98 PA3 SUB_Power_Cont PD O O/L O/L O/L Power Control (+3.3V_D1 / +12V_A)
99 PA2
VBUS_Power_
Cont
PD_OPEN O O/L O/L O/L Unused ("L" input set)
100 PA1 HP/DET PU I I I I H/P detect
101 PA0 /B1/B2 PD O O/L O/L O/L
Route Selection of Front USB and iPod Dock
("L": Dock, "H": Front USB)
102 PE7 AUX_DET PU I I I I Portable IN detect
103 PE6 DOCK_DET PU I I I I iPod Dock Detect
104 PE5 WPS PU I I I I WPS start("L" continued for 3 seconds)
105 PE4 SRAMSTB PU O O/L O/L O/L SRAMSTB Control for CD DSP
106 PE3 BUS3 PU I/O O/L O/L O/L CD DSP (TC94A92FG) Control
107 PE2 BUS2 PU I/O O/L O/L O/L CD DSP (TC94A92FG) Control
108 PE1 BUS1 PU I/O O/L O/L O/L CD DSP (TC94A92FG) Control
109 PE0 BUS0 PU I/O O/L O/L O/L CD DSP (TC94A92FG) Control
110 PD7 CCE PU O O/L O/L O/L CD DSP Control (Chip Enable)
111 PD6 BUCK PU O O/L O/L O/L CD DSP Control (BUS CLK)
112 PD5 OPSW PU I I I O/L Open SW from CD Mecha
113 PD4 CLSW PU I I I O/L Close SW from CD Mecha
114 P64 INSW PU I I I O/L Limit SW from CD Mecha
115 P63 DECRST PU O O/L O/L O/L Reset for CD DSP (TC94A92FG)
116 P62 DREQ - I I I O/L CD DSP (TC94A92FG) DREQ
117 P61 SBSY PU I I I O/L
CD Monitor (Default: SBSY) from CD DSP
(TC94A92FG)
118 P60 DRVMUTE PU_OPEN O O/L O/L O/L CD Driver Mute ("H": Mute Off, "L": Mute On)
119 PD3 CD_OPEN - O O/L O/L O/L Open CD Tray
120 PD2 CD_CLOSE - O O/L O/L O/L Close CD Tray
121 PD1 VBUS_FLUG1 PU I I I I Check VBUS Voltage 1 (Front USB), "L" : Error
122 PD0 VBUS_FLUG2 PU I I I I Check VBUS Voltage 2 (iPod Dock), "L" : Error
123 P97 LD_CHK AD I I I O/L Check CD Laser Diode Current
124 P96 VBUS_CTL1 PD O O/L O/L O/L VBUS Control 1 (Front USB)
125 P95 VBUS_CTL2 PD O O/L O/L O/L VBUS Control 2 (iPod DOCK)
126 P94
DM_VBUS_
CONT
PD O O/L O/L O/L DM870 VBUS Control
127 P93 TEST4 PD I I I I Boot for Check PCB mode
128 P92 LED_WT PU O O/L O/L O/L Control White LED (POWER ON : "H")
129 P91 LED_RED PD O O/H O/H O/L Control Red LED (ECO-STBY : "L")
130 VSS VSS - - - - - GND
131 P90 LED_GREEN PD O O/L O/H O/L Control Green LED (ECO-STBY : "L")
132 VCC VCC - - - - - +3.3V_CPU
133 P47 MODEL AD I I I I Model Select ("L": N5, "H": N8)
134 P46 REGION AD I I I I
Region Select ("0V": E2/H, "3.3V": E3/MID,
"1.5V": JP)
135 P45 DC Protect 1 PU I I I I Power Down Detect : Unused (H input set)
136 P44 DC Protect 2 PU I I I I Power Down Detect
137 P43 REMOTE PU(OPEN) I I I I Remote Input
138 P42 KEY3 PU I I I I Key Input 3 (A/D Port)
139 P41 KEY2 PU I I I I Key Input 2 (A/D Port)
140 VREFL VREFL -
- - - - GND
141 P40 KEY1 PU I I I I Key Input 1 (A/D Port)
142 VREFH VREFH - - - - - +3.3V_CPU
143 AVCC
AVCC - - - - - +3.3V_CPU
144 P05 TCK PU I I I I Emulator Connection terminal
