Section III Installation
Upholstery (Continued)
Headrest
1. Slide the blade of the standard  xed headrest
(Figure 20) or the optional double articulating
headrest (Figure 21) into the opening of the
back casting, making sure the blade aligns
with the nylon guides inside the chair back.
Standard
Fixed
Headrest
Blade
Figure 20. Standard  xed headrest
Blade
Double
Articulating
Headrest
(Optional)
Chair Back
Casting
Opening
Figure 21. Double articulating headrest (optional)
2. Place the magnetic headrest cushion on the
chair or the  xed headrest of the chair.
Magnetic
Cushion
Figure 22. Headrest shown with magnetic cushion
The headrest shown (Figure 22) contains
magnets, which can interfere with the
function of some medical devices, including
pacemakers. A minimum distance of 4" is
required to reduce the magnetic  eld level
below 10 gauss.
WARNING
