Section VII Parts Lists/Diagrams
Controls
Part/Kit Name Part/Kit No.
Touchpad Switch, RH 3802-423
Touchpad Switch, LH 3802-441
Touchpad Circuit Board 3802-424
Foot Control Option (Wireless) 3625-815
Handpiece Safety Switch Option 3625-562
Wireless Touchpad 3625-827
Wired Foot Switch 3625-858
Battery Box (Wireless) 3802-521
Electrical
Part/Kit Name Part/Kit No.
Master Circuit Board (115V AC) 3802-425
Master Circuit Board (220V AC) 3802-426
Fuses (115V AC) 3801-766
Fuses (220V AC) 3801-767
Main Wiring Harness 3802-429
Power Cord (115V AC) 3802-430
Power Cord (220V AC) 3802-431
Pump Motor Capacitor (115V AC) 3801-897
Pump Motor Capacitor (220V AC) 3802-433
Base Potentiometer 3802-436
Limit Switch (All) 3801-431
Back Potentiometer Assembly 3802-438
Touchpad Control Wiring (Switch to Switch) 3802-440
USB Option 3625-807
LED Display/Harness Bracket 3802-501
Mechanical
Part/Kit Name Part/Kit No.
Spring 3802-461
Arm Assembly (Right) 3802-462
Arm Assembly (Left) 3802-463
Brake Handle 3802-465
Air Glide Caster 3801-680
Air Glide Regulator 3801-791
Air Glide Toggle Switch 3801-792
Rear Spring Mount Upgrade Kit 3658-475
Lower Brake Assy. Washer Replacement Kit 3802-494
Upholstery
Part/Kit Name Part/Kit No.
Seamless Seat Cushion 3802-466
Seamless Seat Cushion, Ultra 3802-466U
Seamless Back Cushion 3802-467
Seamless Back Cushion, Ultra 3802-467U
Plush Seat Cushion 3802-468
Plush Back Cushion 3802-469
Standard Headrest Cushion 3801-827
Standard Headrest Magnetic Cushion 3801-826
Double Articulating Headrest Cushion, Optional 3801-535
Back Substrate Blind Grip Fasteners 3801-742
Seamed Back Cushion 3802-496
Seamed Back Cushion, Ultra 3802-496U
Seamed Seat Cushion 3802-495
Seamed Seat Cushion, Ultra 3802-495U
Wider Double Articulating Headrest Cushion 3802-282
Wider Dbl. Art. Headrest Cushion, Ultra 3802-283
Padded Arm Cushion 3802-497
Padded Arm Cushion, Ultra 3802-497U
Arm w/Holes for Pad, RH 3802-498
Arm w/Holes for Pad, LH 3802-499
Hydraulic
Part/Kit Name Part/Kit No.
Pump (115V AC) 3802-451
Pump (220V AC) 3802-452
Valve (115V AC) 3802-434
Valve (220V AC) 3802-435
Fluid Reservoir Assembly 3802-455
Base Cylinder 3802-456
Back Cylinder 3802-457
Hose (Pump to Valve) 3802-458
Hose (Valve to Base) 3802-459
Hose (Valve to Back) 3802-460
Base and Back Cylinder Vent Tubing 3801-418
Pump and Reservoir Tubing 3801-417
Hydraulic Oil (One Pint) 3801-549
Exterior Components
Part/Kit Name Part/Kit No.
Pump Cover 3802-442
Bottom Cantilever Cover 3802-443
Top Cantilever Cover 3802-444
Chair Pivot Cover 3802-445
Brake Cover 3802-446
Left Side Spring Cover 3802-447
Right Side Spring Cover 3802-448
Left/Right Arm Plug 3802-449
Arm Latch Plug 3802-450
