Service Manual CEREC Primescan AC, Primescan AC, CEREC Omnicam AC, Omnicam AC
4 Repair
4.3 Replacing parts (without removing covers)
66 81 832 D3696
D3696.076.01.02.0205.2019
101
4.3.2.6
Replacing the DVD drive (optional)
1.
Open the service cover on the rear side (see "Opening the service
cover [→52]").
2.
Detach the DVD drive connector.
3.
Unscrew the 3 fastening screws and pull out the DVD drive with the
retaining plate.
4.
Detach the three M2 screws and remove the DVD drive from the
retaining plate.
5.
Install the new DVD drive in the retaining plate.
6.
Slide in the new DVD drive using the guide rails up to the stop and
screw it in place with the 3 fastening screws.
7.
Attach the DVD drive connector.
8.
Insert the service cover and lock it (see "Closing the service cover
[→52]").
