Dentsply Sirona Omnicam AC User Manual

4 Repair
4.3 Replacing parts (without removing covers)
Dentsply Sirona
Service Manual CEREC Primescan AC, Primescan AC, CEREC Omnicam AC, Omnicam AC
102
66 81 832 D3696
D3696.076.01.02.0205.2019
4.3.2.7
Opening the PC
ü The PC is removed (see "Replacing the PC including the power
supply unit [→94]").
1.
Turn the PC onto its side as shown.
2.
Unscrew the 3 screws (
A
).
3.
Push the cover forwards approximately 2 cm. In this process, the
seal will tear.
4.
Lift up the cover on the right side slightly and pull it out to the right.
4.3.2.8
Replacing the SSD module
1.
Open the PC (see "Opening the PC [→102]").
2.
Unscrew the fastening screw.
Ä The SSD module springs upwards on the right-hand side.
3.
Pull out the SSD module to the right.
