CONCRETE MIXER
EN
№ Standard Appilation Qty. № Standard Appilation Qty.
1 Upside of tank 1 33 14×1,5 Adjusting washer 14×1,5 3
2 М8×16 Bolt М8×16 10 34 Pinion gear 1
3 Rubber packing 1 35 6×30 Locking pin 6×30 1
4 М8×12 Bolt М8×12 5 36 6202 Bearing 6202 2
5 Crown 1 37 30 Snap ring Ø 30 1
6 Underpart 1 38 62 Snap ring Ø 62 3
7 U-shaped clamp 1 39 Anther 1
8 М8×20 Bolt М8×20 2 40 3,5×16 Self tapping screw 3,5×16 2
М8 Common washer М8 2 41 Switch 1
М8 Spring washer М8 2 42 Gasket 1
М8 Nut М8 2 43 Tension protection 1
9 Steering wheel 1 44 Power cord 1
10 Tank traverse 1 45 Strain relief housing 1
11 Drum lock extension 1 46 Gasket for strain relief housing 1
12 Spring 1 47 Nut for strain relief housing 1
13 М6×25 Bolt М6×25 1 48 Motor mount bracket 1
14 М8 Nut М8 2 49 М8×30 Bolt М8×30 3
15 Stand frame 1 50 47 Snap ring Ø 47 1
16 4×20 Cotter pin 4×20 1 51 30 Snap ring Ø 30 1
17 Drum lock lever 1 52 6906 Bearing 6906 2
18 М8 Spring washer М8 2 53 4,8×16 Self-threaded screw 4,8×16 9
19 М8 Nut М8 2 54 End plate 1
20 М6 Nut М6 1 55 Washer 1
21 Frame 1 56 Belt 1
22 М8×70 Bolt М8×70 3 57 Pulley 1
М8 Common washer М8 3 58 Motor 1
М8 Spring washer М8 3 59 Fan 1
М8 Nut М8 3 60 Motor cover 1
23 Wheel axle frame 1 61 М10×20 Bolt М10×20 4
24 Wheel 2 62 М10 Rubber washer М10 4
25 R4×90 Spring cotter pin R4×90 2 63 М10 Spring washer М10 4
26 М6 Plain washer М6 2 64 Blade 2
27 42 Snap ring Ø 42 1 65 М10 Nut М10 4
28 42 Snap ring Ø 42 1 66 М10 Plain washer М10 4
29 42 Ring Ø 42 1 67 Large safety gear 1
30 М8 Nut М8 2 68 Shaft mount 1
31 6202 Bearing 6202 2 69 Safety gear small 1
32 Drive shaft 1 70 М8×65 Bolt М8×65 1
