19
4. Rotate the spring clip under the rear
wheel assembly beam for protection.
THE BATTERY
Fitting the battery
1. The battery ts into the box under
the seat with the cables coming
out from the opposite side to the
connector socket (see diagram).
2. Align the connector and plug
so that the connector pins can
be easily pushed into the plug.
Once it is located, rotate the collar
clockwise to secure.
3. Ensure straps and wires are
positioned appropriately to prevent
damage and to avoid them
interfering with the seat adjustment.
cable
connector
