34
Metal Tray
The tray, if supplied, is designed especially for use with
alternative controls and is easy and quick to remove. Please note
that the metal tray is an optional extra.
The tray is manufactured specically to t on the left or right hand
side. It will only t the side for which it was manufactured.
To t the tray, pull the black hand-screw outwards and lift
the wrist pad up and out of the mounting block. Let it hang
suspended by its rubber tether. Take hold of the tray and again
pull the black hand-screw outwards. Lower the mounting pin of
the tray into the mounting block until the tray rests on the support
plate. Release the black hand-screw. Rotate the tray slightly, until
the black hand-screw locates in place.
To remove the tray repeat the above procedure in the reverse order.
Use of switches
Large button switches can be mounted on a tray and pressed to
move Wizzybug. Four switches can be used to drive Wizzybug:
forwards, backwards, right or left. Each switch has a wire and
connector that is plugged into the DX Switch Module which plugs
into the DX joystick.
Use of Moozi
The Moozi is a low prole switch joystick designed by MERU for
use mounted on a tray. Connection is through a DX Switch Module
which is plugged into the DX joystick.
