48
Maximum Current 120 amps
Turning Circle 470mm / 18.5in
Overall width of vehicle 560mm / 22in
Overall length of vehicle 650mm / 25.6in
Total weight of vehicle 31.3kg / 69 lbs
Weight of heaviest part 16.4kg / 36 lbs
Maximum speed 2.9km/hr or 1.8 mph (speed can
be limited)
Obstacle climbing 40mm / 1.6in
Obstacle clearance 40mm / 1.6in
Dynamic stability uphill 13°
Static stability downhill 21°
Static stability sideways 11°
Seat width 235mm / 9.3in
Seat depth 155mm - 245mm or 6.1 - 9.7in
Seat height 360mm or 14.2in
Backrest angle Adjustable from 90 - 97°
Backrest height 410 - 430mm
Seat Plane Angle (Tilt) 0 - 15°
Footrest to seat 150mm - 275mm or 16.1 - 10.8in
Leg to seat surface angle 90°
Max weight of user 20.0kg / 44lbs
Standard Battery (Lead Acid)
Upgrade Battery (Nickel Metal Hydride)
24V, 10Ah, SLA
24V, 15Ah, NiMH
Overall Height (headrest not fully extended) 870mm / 34.3in
Minimum width of corridor in which Wizzybug can
be turned to be facing in the opposite direction
900mm / 35.4in
Measured sound power level Indoor <65dB
Outdoor <75dB
Battery nominal voltage Lead Acid = 12V
Nickel Metal Hydride = 24V
Specification
Fig 44 Specications
