ATTACHING THE FOOTREST TO WIZZYBUG
The footrest can be attached before or after the child is seated.
• Squeeze the spring mechanism under the
footrest.
• Push the footrest into the back slot at the
required height then release the spring
mechanism to engage the footrest pins in
the side slots required.
• Ensure the footrest is locked in the
required position before using.
• The height is adjustable using the metal grid
and colour codes.
Fig. 10 Attaching the footrest to Wizzybug (from top left, clockwise) Spring mechanism, height of the
footrest - showing the back-plate with the coloured pin slots, footrest tilt adjustment using the side slots.
The footrest can be level or tilted to match the tilt-in-space
angle of the seat position. Ideally your child’s feet should sit at
on the footplate.
Use the colour-coding to set the height and angle of the footrest.
The colour-code at the back of the footrest matches with a choice
of slots of the same colour positions at the sides. If you choose
the lowest same colour position on the sides the footrest is level.
The footrest can be tilted upwards or downwards by choosing a
different position for the locating pins at the sides.
