Designability WizzyBug - Setting Up the Controls

38
Positioning of the joystick
Reach adjustment
The position of the joystick can be adjusted using the black hand-screws.
It is possible to reposition the joystick unit closer to the armrest by
repositioning the black hand-screw under the armrest in the rear
hole of the armrest plate.
There is a cover on the joystick that can be removed to allow you to
slide the joystick closer to the armrest.
Height adjustment
The height of the joystick can be set by adjusting the height of
the armrest. The armrest height is adjusted using the black hand-
screw on the backrest.
Fig 34 Reach adjustment on Wizzybug
Fig 35 Joystick cover
Fig 36 Height adjustment of the joystick
