11/20168 / 72
6159931430
Issue no: 05
Series: -
BIT MODULE FOR SCREWDRIVER BITS
Range of bits
HEX 4 to 8
TORX 25 to 40
Mounting
17.7 mm
● Remove the V-shaped part.
● Place the module and secure it by using the
M5x20 screw supplied in the packing box.
Operation
2
1
Legend
1 Bit hole
2 Screw
● Insert the bit in the hole.
● Turn the screw clockwise for a heavier bit
and counter-clockwise for a lighter bit.
