02/2014 43 / 72
6159933910
Issue no: 04
The ToolsNet software can be used to recover the
tightening results and the curves on PC via Ethernet.
This screen is the conguration of the ToolsNet data
collector.
Type of system for ToolsNet server (3
is the default: OP Undened controller)
Identication of the system in the
controller network (group of stations)
Identication of the station in the
controller network (individual station)
When the result memory to be
transmitted is full, the start cycle that
follows can be locked or not (the start
cycle is not locked on, but next results
are not saved).
When the memory lling rate reaches
this value (1 to 99%), an alarm is
displayed.
Check the box to synchronize the
controller date with the ToolsNet
server.
Memory space allocated for not
transmitted results
Memory space used in the FIFO
NOK: not connected to the CVINET
server.
OK: connection established.
