02/2014 5 / 72
6159933910
Issue no: 04
This product is intended to be used to drive, monitor and
control the EC/ER/MC range tools.
No other use permitted.
For professional use only.
EMC restriction of use: for industrial use only.
To reduce risk of injury, everyone using,
installing, repairing, maintaining, changing
accessories on, or working near this tool must
read and understand the safety instructions
before performing any such task. Failure to
follow all instructions listed below may result in
electric shock, re and/or serious personal injury.
General safety instructions are collected in the
6159931790 tool safety booklet and quick start user
manual 6159932180.
The electric tightening system is automatically controlled
by measuring the power consumption of the tool and
monitoring the angle rotation.
This technology provides a complement to the range of
traditional systems tted with a torque transducer.
The electric power tool are either hand held (EC), xed
(ER / MC) series.
CVIR II range is composed of 2 models, 2 hardware
models:
● One to drive low torque tools as ECS.
● The other to drive the more powerful tools
(ending by 4).
All models allow up to 15 tightening cycles.
The different models are:
● CVIR II.
● CVIR II H4.
Quick cycle X
Learning mode X
Number of cycles 50 50
Number of phases available 15 15
Search sequence X X
Approach X
Run down speed X X
Final speed phase X X
Action on NOK X X
Run reverse X X
Jump to another phase X X
Prevailing Torque X
Synchronisation phase X
Disengage X
Torque X X
Torque with angle monitoring X X
Angle with torque monitoring X X
Yield point X
Seating detection X
Number of stored results
2000 to 10000
according
conguration
CVIR II controllers are equipped of the following
communication facilities:
● 1 Ethernet ports for CVIPC or network
communication.
● 1 RS232 port to connect barcode readers or
CVIPC 2000
● 8 Logical Inputs and 8 logical Outputs.
● Optional eldbus module.
The complete range of Current Control tool can work
with CVIR II controllers. Every tool has a memory.
When connecting the tool to a controller, the controller
recognizes the tool and set automatically all specic
parameters.
The selection of the tool takes account of the operating
conditions as stated by the user, who shall not exceed
the operating limits as specied by the manufacturer at
the time of the selection (see "Max duty cycle" le on the
CDRom supplied).
Any excessive internal temperature (over 100°C) of the
tool electric motor is detected and stops the tool. It can
start again only if the temperature decreases below
80°C.
