Despatch MIC 1422 User Manual

46
STEP DESCRIPTION DISPLAY
CODE
AVAILABLE SETTINGS FACTORY
SETTING
5 Output 2 Usage USE2 Out2=Control (opposite of Out1
action)
Hy_r=Alm Hyst Rev Act**
Hy_d=Alm Hyst Dir Act***
LP-r=Loop Reverse
LP-d=Loop Direct
Ad-r=Rev Logic AND
Ad-d=Dir Logic AND
Or-r=Rev Logic OR
Or-d=Dir Logic OR
A2_r=Alm 2 Rev
A2_d=Alm2 Dir
Out2
6 Output 3 Usage USE3 Al-d=Alm 1 Dir
rEcP=Rcdr Out RV.
rEcS=Rcdt Out S.R
LP-r=Loop Reverse
LP-d=Loop Direct
Ad-r=Rev Logic AND
Ad-d=Dir Logic AND
Or-r=Rev Logic OR
Or-d=Dir Logic OR
Al-r=Alm 1 Rev
Hy-d=Alm Hyst Dir Act***
Hy-r=Alm Hyst Rev Act***
A1_d
7 Com Bit Rate CbS 1200, 2400, 4800, 9600 4800
8 Com Parity CPAr nonE, odd, EvEn none
9 Com Address CAd 1-255 1
10 CJC Enable CJC EnAb
disA
EnAb
11 Decimal Position dPoS 0, 1, 2, 3 (Linear Input Only) 1
12 Engineering Units
Upper
Euu -1999 to 9999 1000
13 Engineering Units
Lower
EuL -1999 to 9999 0
14 Setpoint
Upper Limit
SPUL Span Max. Span Max.
15 Setpoint
Lower Limit
SPLL Span Min. Span Min.
16 Remote Setpoint
Maximum
rSPu - 1999 to 9999 PV Range
Maximum
17 Remote Setpoint
Minimum
RSPL - 1999 to 9999 PV Range
Minimum
18 Output 1% Limit o1PL 0 to 100% 100
19 Process Output
Upper
Pou - 1999 to 9999 Span Max.
20 Process Output
Lower
PoL -1999 to 9999 Span. Min.
