APPENDIX B: RANGE CODES
The input ranges available (selectable via the front panel) are:
For Thermocouple Inputs
TYPE INPUT RANGE DISPLAYED
CODE
R 0 - 1650°C 1127
R 32 - 3002°F 1128
S 0 - 1649°C 1227
S 32 - 3000°F 1228
J 0.0 - 205.4°C 1415
J 32.0 - 401.7°F 1416
J 0 - 450°C 1417
J 32-842°F 1418
J 0 - 761°C 1419
J 32 - 1401 °F 1420
T -200 - 262°C 1525
T -328 - 503°F 1526
T 0.0 - 260.6°C 1541
T 32.0 - 501.O°F 1542
K -200 - 760°C 6726
TYPE INPUT
RANGE
DISPLAYED
CODE
K -328 -1399°F 6727
K -200 - 1373°C 6709
K -328 - 2503°F 6710
L 0.0 - 205.7°C 1815
L 32.0 - 402.2°F 1816
L 0 - 450°C 1817
L 32 - 841°F 1818
L 0 - 762°C 1819
L 32 - 1403°F 1820
B 211 - 3315°F 1934
B 100 - 1824°C 1938
N 0 - 1399°C 5371
N 32 - 2550°F 5324
For RTD Inputs
Note: Input conditioning jumper LJ1, LJ2, or LJ3 needs to be changed, see Appendix A.
INPUT RANGE DISPLAYED CODE
0 - 800°C 7220
32 - 1471 °F 7221
32 - 571 °F 2229
-100.9 - 100.O°C 2230
- 149.7 - 211.9° F 2231
0 - 300°C 2251
INPUT RANGE DISPLAYED CODE
0.0 - 100.9°C 2295
32.0 - 213.6°F 2296
-200 - 206°C 2297
-328 - 402°F 2298
- 100.9 - 537.3°C 7222
- 149.7 - 999.1 °F 7223
