95-8704
18
2.7
ENCLOSURE MATERIAL—
Copper-free aluminum (painted) or Stainless
Steel (316/CF8M Cast).
VIBRATION—
Conformance per FM 3260: 2000, MIL-STD
810C (Curve AW), DNV Note 2.4 (Class B).
WIRING—
Field wiring screw terminals are UL/CSA rated
for up to 14 AWG wire, and are DIN/VDE rated
for 2.5 mm
2
wire. Screw terminal required torque
range is 3.5–4.4 in.-lbs. (0.4-0.5 N·m).
Important: 18 Vdc minimum must be available
at the detector. For
ambient temperatures
below
–10°C (14°F) and above +60°C (140°F) use field
wiring suitable for both minimum and maximum
ambient temperature.
THREAD SIZE—
Conduit connection: Four entries, 3/4 inch NPT or
M25. Conduit seal not required.
SHIPPING WEIGHT (Approximate)—
Aluminum: 7 pounds (3.2 kilograms).
Stainless Steel: 13.8 pounds (6.3 kilograms).
Mounting Arm (AL): 6 pounds (2.75 kilograms).
Mounting Arm (SS): 14 pounds (6.4 kilograms).
WARRANTY PERIOD—
5 years.
CERTIFICATION—
®
VdS
For complete approval details, refer to the
appropriate appendix:
Appendix A - FM
Appendix B - CSA
Appendix C - ATEX
Appendix D - IECEx
Appendix E - EN54
Appendix F - Offshore
Appendix G - Additional Approvals
Appendix H - Declaration of Conformity
