19
95-8704
2.7
REPlaCEmENT PaRTS
The detector is not designed to be repaired in
the field. If a problem should develop, refer to
the "Troubleshooting" section of this manual. If it
is determined that the problem is caused by an
electronic defect, the device must be returned to
the factory for repair.
REPLACEMENT PARTS LIST
Part Number Description
009208-001
o
i
Replacement kit for X3301 (5 Black Reflector Plates)
with Inspector Connector and Monitor
010831-001
o
i
Replacement kit for X3301 (5 Stainless Steel Reflector
Plates) with Inspector Connector and Monitor
007307-001
Replacement o
i
Reflector Plates for X3301 with Black plate
(requires Inspector Connector to calibrate)
010830-001
Replacement o
i
Reflector Plates for X3301 with Stainless
Steel plate (requires Inspector Connector to calibrate)
NOTE: Refer to instruction manual 95-8530 to determine the correct
o
i
Replacement Plate.
DEVICE REPaIR aND RETURN
Prior to returning devices, contact the nearest
local Detector Electronics office so that a Return
Material Identification (RMA) number can be
assigned. A written statement describing the
malfunction must accompany the returned
device or component to assist and expedite
nding the root cause of the failure.
Pack the unit properly. Always use sufficient
packing material. Where applicable, use an
antistatic bag as protection from electrostatic
discharge.
NOTE
Det-Tronics reserves the right to apply a
service charge for repairing returned
product damaged as a result of improper
packaging.
Return all equipment transportation prepaid to the
factory in Minneapolis.
NOTE
It is highly recommended that a complete
spare be kept on hand for eld replacement
to ensure continuous protection.
ORDERING INfORmaTION
When ordering, please specify:
X3301 Multispectrum IR Flame Detector
Refer to the X3301 Model Matrix for details
Q9033 Mounting Arm is required:
– Q9033A for aluminum detectors only
– Q9033B for aluminum and stainless steel
detectors
ACCESSORIES
Part Number Description
103881-001 Converter RS485 to USB
007819-002
W6300B1003 USB Inspector Connector
(Enhanced Flame Inspector software included)
009207-001
Enhanced Flame Inspector CD
103922-001
Model 475 HART Communicator
102740-002
Magnet
008082-001
Magnet and Adapter for Extension Pole
007739-001
Magnet and Extension Pole
007240-001 Q1116A1001, Air Shield (AL)
007818-001
Q1118A1001 Aluminum Air Shield/Flange Mount (AL)
007818-002
Q1118S1001 Stainless Steel Air Shield/Flange
Mount (SS)
009177-001
Q1120A1001 Paint Shield mounting ring (AL)
010857-001 Q1130A1001 Flange Mount Assembly
006097-002 Q1201 Green Laser
102871-001
Laser Battery, 3V Lithium (laser)
007255-001 Q1201C1001 X-Series Laser Holder (AL/Plastic)
007338-001
Q2000A1001 X-Series Weather Shield (AL)
007338-010
Q2033A10R X3301/X3302 FOV Limiter 10° (AL)
007338-020
Q2033A20R X3301/X3302 FOV Limiter 20° (AL)
007338-030
Q2033A30R X3301/X3302 FOV Limiter 30° (AL)
007912-010
Spare Restrictor Plate 10° (AL)
007912-020
Spare Restrictor Plate 20° (AL)
007912-030
Spare Restrictor Plate 30° (AL)
007290-001
Q9033B Stainless Steel Mounting Arm Assembly
is for aluminum and stainless steel detectors
007290-002
Q9033A Aluminum Mounting Arm Assembly is for
aluminum detectors only
011385-001
Q9033 Collar Attachment
101197-001
Stop Plug, 3/4” NPT, AL
101197-004
Stop Plug, 3/4” NPT, SS
101197-005
Stop Plug, M25, AL, IP66
101197-003
Stop Plug, M25, SS, IP66
010816-001
Stop Plug, 20 Pack, 3/4”NPT, AL
010817-001
Stop Plug, 20 Pack, 3/4”NPT, SS
010818-001
Stop Plug, 20 Pack, M25, AL, IP66
010819-001
Stop Plug, 20 Pack, M25, SS, IP66
103363-001
14 mm Hex Wrench (Steel)
103406-001
Screwdriver
001680-001 Window cleaner (6 pack)
107427-040
005003-001
O-ring - Rear Cover (Viton) - black or brown
1 oz grease for detectors (silicone-free)
104346-154
012549-001
O-ring - Rear Cover (Fluorosilicone) - blue
1 oz PTFE silicone-free lubricant
000003-067 Stainless Steel Sun Shade
000609-026 4" Pipe Mount Bracket and U-Bolt Kit
000609-035 2" Pipe Mount U-Bolt Kit
