95-8704
20
2.7
X3301 MODEL MATRIX
MODEL DESCRIPTION
X3301 Multispectrum IR Flame Detector
TYPE MATERIAL
A Aluminum
S Stainless Steel (316)
TYPE THREAD TYPE
4M 4 Port, Metric M25
4N 4 Port, 3/4" NPT
TYPE OUTPUTS
11 Relay
13 Relay and 0-20 mA
14 Eagle Quantum Premier (EQP)
15 Relay and Pulse
16 Addressable Module Only (Third Party Type)*
21 Relay-Automotive
22 EQP Automotive
23 HART, Relay and 0-20 mA
TYPE APPROVALS**
B INMETRO (Brazil)
R VNIIPO/VNIIFTRI (Russia)
T SIL/FM/CSA/QPS***/ATEX/IECEx
W FM/CSA/QPS***/ATEX/IECEx
TYPE CLASSIFICATION
1 Division/Zone Ex d e
2 Division/Zone Ex d
*The Addressable Module Only (Type 16) is not FM approved.
**Type Approvals can use one or more letters to designate
the approvals of the product.
***QPS approval applies to output types 11, 13, 15, 21, and 23.
