95-8704
38
2.7
aPPENDIX f
OFFSHORE APPROVALS
USCG APPROVAL
Coast Guard Approval No. 161.002/49/0
The scope of this approval is for a fire detection system meeting 46 CFR 161.002, as part of the Eagle Quantum Premier System.
MARINE EQUIPMENT DIRECTIVE
DNV Certificate No. MED-B-9427
Is found to comply with the requirements in the following Regulations / Standards:
Annex A.1, item No. A.1/3.51 and Annex B, Module B in the Directive. SOLAS 74 as amended, Regulation II-2/7 & X/3,
2000 HSC Code 7, FSS Code 9 and IMO MSC.1/Circ. 1242.
The equipment are found to comply with following location / application dependent requirements
(for definition of each of the location classes, see below the table):
MODEL TEMPERATURE VIBRATION EMC ENCLOSURE
X3301 TEM-D VIB-B EMC-B ENC-C
Definition of the location classes with reference to relevant standards:
Temperature
TEM-D Location (–25°C–70°C) (ref. IEC 60092-504 (2001) table 1 item 6-7)
Vibration
VIB-D For eq. on reciprocating machines etc. (ref IEC 60092-504 (2001) table 1 item 10)
EMC
EMC-B Bridge and open deck zone (ref. IEC 60092-504 (2001) table 1 item 19-20)
Enclosure
ENC-C Open deck (IP56) (ref. IEC 60092-201 table 5)
Conformity to Module D, E and F.
TYPE APPROVAL
DNV Certificate No. TAA00000V2.
Subject Matter of the Approval
IR Flame Detector Type X3301 for use in Ships, High Speed & Light Craft, and Offshore Applications.
Application Location Classes:
Location classes for X3301 IR Flame Detector with Mounting Arm Q9033B / Q9033A and optional Q9033 Collar Attachment (Shaded areas show Det-
Tronics approved location classes)
COLUMN 1 COLUMN 2
TYPE LOCATION WITHIN MAIN AREA
MAIN AREAS ON BOARD
Machinery
spaces
Control room,
Accommodation
Bridge
Pump room, Holds,
Rooms with no heating
Open Deck
Temperature
Inside cubicles, desks, etc. with temperature rise of 5°C or more B B B D D
All other locations A A A C D
Humidity
Locations where special precautions are taken to avoid
condensation
A A A A A
All other locations B B B B B
Vibration
On machinery such as internal combustion engines, compressors,
pumps, including piping on such machinery
B — — B B
Masts — — — — —
All other locations A A A A A
EMC (Electro-
magnetic
compatibility
All locations within specified main areas A A B A B
Enclosure
Submerged application D — — D D
Below floor plates in engine room C — — — —
All other locations B A A B C
The following accessories are offshore approved to the listed approvals, for use with the X3301 Flame Detector:
Part Number Description
102740-002
Magnet
007739-001
Magnet and Extension Pole
007290-001
Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
007290-002
Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
011385-001
Q9033 Collar Attachment
