aPPENDIX B
CSA APPROVAL
DIVISION CLASSIFICATION:
Multispectrum IR Flame Detector/Controller X3301 Series, rated 18–30 Vdc, 4.6–17 Watts.
Relay contacts rated 30 Vdc, 5 Amps.
CLASS 4818 04 - SIGNAL APPLIANCES - Systems - For Hazardous Locations
Class I, Division 1, Groups B, C, and D (T4A); Class II, Division 1, Groups E, F, and G (T4A);
Class I, Division 2, Groups A, B, C, and D (T3C); Class II, Division 2, Groups F and G (T3C);
Class III; Enclosure NEMA/Type 4X;
Conduit seal not required.
APPLICABLE REQUIREMENTS
CAN/CSA-C22.2 No. 0-M91 – General Requirements — Canadian Electrical Code, Part II
CAN/CSA-C22.2 No. 25-1966 – Enclosures for use in Class II Groups E, F, and G Hazardous Locations
CAN/CSA-C22.2 No. 30-M1986
– Explosion-Proof Enclosures for use in Class I Hazardous Locations
CAN/CSA-C22.2 No. 94-M91
– Special Purpose Enclosures
CAN/CSA-C22.2 No. 142-M1987
– Process Control Equipment
CAN/CSA-C22.2 No. 213-M1987
– Nonincendive Electrical Equipment for use in Class I, Division 2 Hazardous Locations
ZONE CLASSIFICATION:
CLASS 4818 04 - SIGNAL APPLIANCES - Systems - For Hazardous Locations
Ex db eb IIC T6...T5
T6 (Tamb = -50
o
C to +60
o
C)
T5 (Tamb = -50
o
C to +75
o
C)
Ex tb IIIC T130
o
C
(Tamb = -50
o
C to +75
o
C)
Seal required adjacent to enclosure
IP66
Ex db IIC T6...T5
T6 (Ta -55
o
C to +60
o
C)
T5 (Ta -55
o
C to +75
o
C)
Seal required adjacent to enclosure
IP66/IP67
APPLICABLE REQUIREMENTS
CAN/CSA-C22.2 No. 60079-0:2015 – Electrical apparatus for explosive gas atmospheres. Part 0: General requirements
CAN/CSA-C22.2 No. 60079-1:2016
– Explosive atmospheres. Part 1: Equipment protection by flameproof enclosures "d"
CAN/CSA-C22.2 No. 60079-7:2012
– Explosive atmospheres. Part 7: Equipment protection by increased safety "e"
CAN/CSA-C22.2 No. 60079-31:2015
– Explosive atmospheres. Part 31: Equipment dust ignition protection by enclosure "t"
The following accessories are CSA approved for use with the X3301 Flame Detector:
Part Number Description
102740-002 Magnet
007739-001 Magnet and Extension Pole
010857-001 Q1130A1001 Flange Mount Assembly
007290-001 Q9033B Stainless Steel Mounting Arm Assembly is for aluminum and stainless steel detectors
007290-002 Q9033A Aluminum Mounting Arm Assembly is for aluminum detectors only
011385-001 Q9033 Collar Attachment
