FM Approval and Performance Report – Continued
Medium Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
L, R (°)
Avg. Resp
Time (s)***
Vertical
Down (°)
Avg. Resp
Time (s)***
Vertical
Up (°)
Avg. Resp
Time (s)***
n-Heptane
1 x 1 foot 75 (22.9) +/– 45 5 +45 4 –30 5
1 x 1 foot 50 (15.2) +/– 45 3 +45 2 –30 3
Isopropanol 6 x 6 inches 45 (13.7) +/– 45 11 +45 8 –30 6
Diesel 1 x 1 foot 60 (18.2) +/– 45 4** +45 6** –30 4**
Ethanol 1 x 1 foot 60 (18.2) +/– 45 7 +45 8 –30 5
Methanol 1 x 1 foot 50 (15.2) +/– 45 5 +45 2 –30 6
Methane 32 inch plume 50 (15.2) +/– 45 5 +45 6 –30 3
Propane 32 inch plume
55 (16.7) +/– 45 5 +45 4 –30 5
Ethane 32 inch plume
55 (16.7) +/– 45 6 +45 5 –30 5
Ethylene 32 inch plume
55 (16.7) +/– 45 7 +45 5 –30 5
Butane 32 inch plume
55 (16.7) +/– 45 6 +45 4 –30 3
JP-5 2 x 2 feet
110 (33.5) +/– 45 7** +45 4** –30 5**
Class A Ø12 in. x 7 in. 40 (12.2) +/– 45 3** +45 3** –30 3**
** Pre-burn from ignition
*** Add 2 seconds for EQP model
Ø Diameter
T-Low Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
L, R (°)
Avg. Resp
Time (s)***
Vertical
Down (°)
Avg. Resp
Time (s)***
Vertical
Up (°)
Avg. Resp
Time (s)***
n-Heptane 1 x 1 foot
35 (10.7) +/– 45 4 +45 4 –30 3
Methanol 1 x 1 foot 20 (6.1) +/– 45 4 +45 4 –30 2
Methane 32 inch plume 20 (6.1) +/– 45 4 +45 4 –30 4
Propane 32 inch plume 20 (6.1) +/– 45 4 +45 4 –30 5
*** Add 2 seconds for EQP model.
Low Sensitivity
Fuel Size
Distance
feet (m)
Horizontal
L, R (°)
Avg. Resp
Time (s)***
Vertical
Down (°)
Avg. Resp
Time (s)***
Vertical
Up (°)
Avg. Resp
Time (s)***
n-Heptane 1 x 1 foot
35 (10.7) +/– 45 8 +45 9 –30 10
Methanol 1 x 1 foot 20 (6.1) +/– 45 9 +45 9 –30 9
Methane 32 inch plume 20 (6.1) +/– 45 9 +45 9 –30 8
Propane 32 inch plume 20 (6.1) +/– 45 9 +45 9 –30 11
*** Add 2 seconds for EQP model.
