0044-0391-0M Rev A y solo Digital Clinical Scale
BATTERY OPERATION, CONT.
4. Install the six (6) new “AA” size batteries in the battery holder, noting the polarity
markings located in the battery holder.
5. Replace the battery cover on the back of the display approximately 3/4” (20mm) from the
right side of the display and then slide it to the right until locks in place (it will click when
locked in place).
6. The display should turn on, show all digits, the software version for a few seconds,
followed by a small 6 moving across the display and then show . on the display.
7. The scale is now ready for operation.
NOTE: If the display did not turn on, remove the battery cover and check for one or more
improperly positioned batteries.
Low Battery
When the batteries are near the point they need to be replaced, /62; will be shown on the
display. If the battery voltage drops too low for accurate weighing, the scale will shut off and
you will be unable to turn it back on. When the /62; message is displayed, the operator
should replace the batteries or remove the batteries and plug-in the 9V AC/DC adapter.
Automatic Shutoff
The Automatic Shutoff feature will turn the scale off after a period of inactivity (no motion
or weight on scale) to prolong battery life. The period of inactivity for the automatic shutoff
is selected during the setup process of the scale and can be set for up to nine (9) minutes.
To turn the scale back on, you simply press the “ ” key.
