0044-0391-0M Rev A y solo Digital Clinical Scale
INSTALLATION
Unpacking
Remove Display with Upper Outside and Inside Column (already assembled), Lower Inside
Column, Lower Outside Column, Scale Platform and Hardware Pack from shipping carton.
After removing from carton, check for any damage that may have taken place during
shipment. Keep and use the original carton and packing material for return shipment if it
should become necessary. The purchaser is responsible for filing all claims for any damages
or loss incurred during transit. Remove all plastic wrapping, foam fillers and cardboard
material from scale platform, display and other components. You should have the following
components:
c Display with Upper Outside and Inside Column (pre-assembled)
d Lower Inside Column
e Lower Outside Column
f Scale Platform (with Column Housing Cover)
g Hardware Pack, containing:
(4) M5 x 15 Machine Screws
(4) Lock Washers
(2) M3 x 12 Screws
To Next Page
