Chinook Gas Furnace User Menus
Main Menus
Status Used to display equipment information
Fault History Display info. on last 6 error codes
2 Week History Display operating info. of last 2 weeks
Life History Display total operating info.
Unit Info Display model and serial numbers
Setup Adjustable settings
Status 1
Parameter Indications Comments
Main Limit Closed , Open Main limit control status
MRLC Input Closed , Open Main reset limit control status
HALC Input Closed , Open Heat assist limit control status
IDM Output Off , Lo , Hi Inducer output status
Furn Lo Pr Sw Closed , Open Low pressure switch status
Furn Hi Pr Sw Closed , Open High pressure switch status
Gas VLV Prcnt % XXX %, Off Gas valve % open
Gas VLV Relay Lo , Hi , On, Off Gas valve control output status
Flame Off , Marginal , Status of flame sensor
Good , Unexpected
Blower CFM CFM XXXX Furnace blower CFM
Status 2
Parameter Indications Comments
Mod Heat ,
Mode Lo Heat , Operating mode of the system
Hi Heat ,
AC1, AC2, Fan, HP1, HP2,
Off
Motor Mfgr Regblt, Emerson Blower motor manufacturer
Motor RPM RPM Blower motro RPM
Maximum CFM CFM XXXX Maximum CFM blower provides
Temp Rise NA, XXXF Temp. diff. between supply and return
Return Temp XXXF, FLT Return air temp. (if installed)
Supply Temp NA (if disabled) , Supply air temp. (if installed and enabled)
XXXF, FLT
HUM Output On , Off Humidifier output relay status
EAC Output On , Off Electronic air cleaner output relay status
Fault History
Fault Code Fautl Occurred Comments
XXXXXXXXXXXXXXX Days XX Displat up to 6 faults;
Days indicates how many days ago the fault occured
Clear Faults No , Yes
2 Week History
Parameter Indications Comments
2wk Lo HT Hrs XXX 2 Week Low Heat Hours of Operation
2wk Lo HT Cycls XXXX 2 Week Low Heat Cycles
2wk Hi HT Hrs XXX 2 Week Low Heat Hours of Operation
2wk Hi HT Cycls XXXX 2 Week Low Heat Cycles
2wk Y1 Hrs XXX 2 Week 1st Stage Cooling/Heat Pump Hours of Operation
2wk Y1 Cycles XXXX 2 Week 1st Stage Cooling/Heat Pump Cycles
2wk Y2 Hrs XXX 2 Week 2nd Stage Cooling/Heat Pump Hours of Operation
2wk Y2 Cycles XXXX 2 Week 2nd Stage Cooling/Heat Pump Cycles
2wk G Hrs XXX 2 Week Blower Hours of Operation
2wk G Cycles XXXX 2 Week Blower Cycles
24
