Life History
Parameter Indications Comments
Total Days Pwrd XXXX Total days control has been powered
Lo HT Hrs XXXXXX Low Heat Hours of Operation
Lo HT Cycles XXXXXX Low Heat Cycles
Hi HT Hrs XXXXXX Low Heat Hours of Operation
Hi HT Cycles XXXXXX Low Heat Cycles
Y1 Hrs XXXXXX 1st Stage Cooling/Heat Pump Hours of Operation
Y1 Cycles XXXXXX 1st Stage Cooling/Heat Pump Cycles
Y2 Hrs XXXXXX 2nd Stage Cooling/Heat Pump Hours of Operation
Y2 Cycles XXXXXX 2nd Stage Cooling/Heat Pump Cycles
G Hrs XXXXXX Blower Hours of Operation
Unit Info
Parameter Indications Comments
Model Number XXXX-XXXXXXXXXXXXXXX Unit model number
Serial Number XXXXXXXXXXXXXXXXXXX Unit serial number
Software Vers XXXXXX Control software version
Setup
Parameter Indications Comments
Heat Rise Adjust 55F, 65F Adjust heat temperature rise
Min Heat Adj % -15, -7, 0, 7, 15 Airflow adjustments at 40% firing rate
Max Heat Adj % -15, -7, 0, 7, 15 Airflow adjustments at 100% firing rate
Supply Air Sens On , Off If sensor is installed, turn on
Reset All Dflts No , Yes Reset furnace settings to factory defaults
Dipswitch *
DIP Indications Comments
Cool Airflow XXXXCFM Airflow setting
Heat Rise % Nom, Nom+10 Temperature rise setting
Min Heat Adj % -15, -7, 0, 7, 15 Airflow adjustments at 40% firing rate
Max Heat Adj % -15, -7, 0, 7, 15 Airflow adjustments at 100% firing rate
Fan Spd Select Lo , Hi Fan speed setting
AC-HP Adj -10%, 0%, 10% AC airflow setting
On-Demand Dehum On , Off Dehumidification setting
Test Mode Off , 40% (70%), 100% Test mode setting
AC HP Stg Mult NA, 50%, 75% Heat pump stage multiplier
* Dipswitch status is not required when system is set up for 4-wire communicatiions. It is only displayed when a
conventional 24V thermostat input is active.
Supreme Electric Furnace User Menus
Status
Parameter Indications Comments
CFM XXXX CFM Current airflow
CMD XXX % % of active electric elements
Version X_X_X Firmware version
AC/HP
1
Parameter Indications Comments
AC/HP 1/2 Tons 0-10, FC* Heat pump size in 1/2 tons
Mode EFF, CO % Efficient or Comfort mode
CFM/TON 300-500, FC* Airflow per ton
AC Y1 Ratio 70-90, FC* %CFM 1st stage cooling
1
The items of this menu are locked or unused when connected to a communicating Alizé Heat Pump.
25
